    Pharmaceutical Ointment Automatic Cartoning Machine With Long Service Life

    Automatic Ointment Pharmaceutical Small Cartoning Box Packaging Machine

    Introduction of cartoning machine:

    This cartoning box packing mchinery has high integration,this automatic horizontal cartoning packing machine can be connected with tail sealing machine,aluminum plastic blister packing machine,strapping machine according to customers’ production requirements.The cartoning mchine equips high degree of automation,from feeding,suction carton,forming,on line transmission,folding of leaflet,material testing,products and leaflet pushing into carton,printing batch number,with top fold flaps,carton sealing(mechanical sealing or hot melt glue),lack of material detection and rejection all automatically completed with improves work efficiency.

    Features of cartoning box packing machine:

    1. All the materials of this horizontal cartoning packing mahine are made of nickel-chromium plated or stainless steel material, with stable chemical performance, corrosion resistance, non-toxicity and harmlessness. The welding position

    is tempered and durable.
    2. The cartonning packaging machine is equipped with protective device. When the machine breaks down, the protective function will be activated immediately. It will not waste materials and ensure the safety of operators.

    3. spare part of this cartoning box packing machine adopt international famous brands, such as Siemens, Baker, Omron, etc.
    4. When the cartoning machine breaks down,the specific situation can be check on the PLC ,convenient to maintenance and repair.

    ModelRQ-ZH-12OW
    Speed30-125 carton/min
    Total power0.750 KW
    Power supply220/380V 50Hz
    Requirements of cartonsize range of carton:L(70-185)*W(35-90)*H(14-50)mm
    carton weight:250-350g/㎡
    Requirements of instructionssize range of instructions:L(78-250)*W(90-170)mm
    range of folding times of instructions:1-4 fold
    instructions weight:60-70g/㎡
    Pressurepressure intensity:≥0.6MPa
    air consumption:120-160 L/min
    Overall size of machine3100*1100*1550㎜
    Net weight of machineabout 1600kg


    When the machine breaks down,the specific situation can be check on the PLC ,convenient to maintenance and repair that save time.

    Easy to adjust, only 3-5 parts need to be replaced to pack products of different sizes.
