Fully Automatic Capsule Filling Machine 72000 Capsules / Hour
Capacity
Introduction of capsule filling machine
Pharmacy capsule filling equipment can fill powder, granules and
other materials into hollow capsules (000#, 00#, 0#, 1#, 2#, 3#,
4#, 5#).This automatic capsule fill machines can automatically
finish the production process including sowing, capsule separating,
filling, locking, unqualified capsule rejected and finished
products output. This pharmaceutiacl automatic capsule filling
machine meets the GMP requirements, it is an ideal equipment for
filling Chinese, Western medicines and health care product.
| Production capacity | 72000 pcs/h |
| Net weight of machine | 1100Kg |
| Overall size of machine | 900×870×1950 |
| Power | 380/220V 50Hz |
| Total power | 5.5KW |
| No.of segment bores | 9 |
| Vacuum | 40m3/h-0.04-0.08Mpa |
| Dust collector | 24.5Kpa 210m3/h |
| Noise | <75DB(A) |
| Making rate | Empty capsule 99.9% Full capsule 99.8% |
| Applicable capsule | 00,0,1,2,3,4,5# |
| Filling error | Western medicine:±3% Chinese medicine:±4% |
| Applicable product | Power,granule,pellet,tablet |
| Weight | 1100Kg |
| Packing size | 1490×1260×2150mm |
Features of capsule filling machine:
1..Rotary of capsule filling machine design to obtain a patent for
utility model, the sealing ring using imported SIL silicone rubber,
effectively prevent powder into the internal turntable, good
sealing performance, no dust overflow pollution.
2.Transverse biaxial adapt PTFE oil-less bearing, no need
refueling; modular structure, equipped with jog operation,
convenient maintenance and cleaning, replacement of mold only 15
minutes,our capsule filling machine is newest.
3.Guangdong Rich Packing Machinery Co. Ltd. has big design
deparment of capsule filling machine,the filling mechanism obtains
the national new patent, adopts the three-dimensional adjustment,
makes the metering plate evenly force, the adjustment volume is
precise and quick, and the powder recovery device is added, the
recycling rate is 100%, which reduces the waste and improves the
economic benefit.
4.This pharmaceutiacl automatic capsule filling meets the GMP
requirements, it is an ideal equipment for filling Chinese, Western
medicines and health care product .
5.Equipped with on-line air pressure die cleaning system, the upper
and lower dies are clean and without dust, improve the sowing
effect.
6.The capsule filler machinery is precision mold concentricity,
zero deviation, ensure that the capsule is not wiping, no damage.
7.Automatic rejection device, improve the charging efficiency ,the
capsule filling equipment is suitable to pharmacy and health care
food manufacture.
8.Our tablet press machine, capsule filling machine, blister
pakcing machine, tablet and capsule counting filling machine,
cartoning box machine are exported to many countries & areas, such
as Korea, India, Indonesia, Pakistan, Thailand, Vietnam, Iran,
Japan, Denmark, Romania, Bulgaria, Russia, South Africa, Nigeria,
the USA, Australia, Canada, Argentina and Chile.
9.What's your payment way?
T/T by our bank account directly, or L/C, or by the West Union, or
in cash.
10.How can you ensure the machine's quality after we put the order?
Before the delivery, we will send you machine's pictures and
videos, or you can come to us to have the quality checking by
yourself, or by the third party inspection organization contacted
by your side.
